Vertiv™ | Liebert
®
STS2
™
100-1000A, 50/60Hz User Manual | Rev. 12 | 11/2017 72
082 LOAD ON ALT SOURCE The output load is running on the alternate source. A, E
083 AUTO REXFER INHIBIT Automatic retransfer is inhibited. A, E
084 CB1 (S1) OPEN Source 1, Circuit Breaker 1 is open. A, E
085 CB2 (S2) OPEN Source 2, Circuit Breaker 2 is open. A, E
086 CB4 (S1 BYP) CLOSED Source 1 on bypass, Circuit Breaker 4 is closed. A, E
087 CB5 (S2 BYP) CLOSED Source 2 on bypass, Circuit Breaker 5 is closed. A, E
088 CB3 (OUTPUT) OPEN Output circuit breaker (CB3) is open. A, E
089 CB3A (OUTPUT) OPEN Output circuit breaker (CB3A) is open. A, E
090 S1 PHASE ROT ERROR Source 1 phase rotation error. A, E
091 S2 PHASE ROT ERROR Source 2 phase rotation error. A, E
092 TRANSFER INHIBITED Transfer inhibited. A, E
093 OUTPUT UV Output is under voltage. D, F, A, E
120
121
122
123
124
125
126
127
INPUT CONTACT #1
INPUT CONTACT #2
INPUT CONTACT #3
INPUT CONTACT #4
INPUT CONTACT #5
INPUT CONTACT #6
INPUT CONTACT #7
INPUT CONTACT #8
Input Contact # x is an optional alarm input. The alarm name can be
programmed with an alarm name from the Input Contactor Isolator
settings option under the Comm Options. See Configuring the Input
Contact Isolator Settings on page 91. The alarm is sent to Monitor DSP.
The LCD logs the alarm with the programmed name. Monitor DSP logs it
with the generic name which is how it is reported to the SVT query.
A, E
128 CONFIG MODIFIED A set point configuration has changed. A, E
129 PASSWORD CHANGED The password for touchscreen access has been modified and saved. A, E
130 TIME REPROGRAMMED The system’s time has been reset and saved. A, E
131 DATE REPROGRAMMED The system’s date has been reset and saved. A, E
132 EVENT LOG CLEARED The event log has been erased. A, E
133 HIST LOGS CLEARED Both History Logs have been erased. A, E
134 HIST LOGS FULL
Both History Logs have been written and no more history logs can be
written without clearing one of the logs.
A, E
Table 5 Event messages (continued)
ID Alarm Message Description/Cause Action
