Vertiv Liebert STS2/PDU - Page 85

Vertiv™ | Liebert
®
STS2
™
100-1000A, 50/60Hz User Manual | Rev. 12 | 11/2017 77
Group 3: User
Settings
1
SCR1 Fast Undervoltage
Setpoint
Integer In % of nominal below nominal
2
SCR1 Slow Undervoltage
Setpoint
Integer In % of nominal below nominal
3
SCR1 Slow Undervoltage
Detect Delay
Integer In number of lines cycles
4 SCR1 Overvoltage Setpoint Integer In % of nominal above nominal
5
SCR1 Overvoltage Detect
Delay
Integer In 1/4 lines cycles
6 SCR1 I peak Transfer Setpoint Integer x 10
7
SCR2 Fast Undervoltage
Setpoint
Integer In % of nominal below nominal
8
SCR2 Slow Undervoltage
Setpoint
Integer In % of nominal below nominal
9
SCR2 Slow Undervoltage
Detect Delay
Integer In number of lines cycles
10 SCR2 Overvoltage Setpoint Integer In % of nominal above nominal
11
SCR2 Overvoltage Detect
Delay
Integer In 1/4 lines cycles
12 SCR2 I peak Transfer Setpoint Integer x 10
13 Max. Transfer Phase Angle Integer In degrees
14 Output Frequency Deviation Integer Freq. in Hz x 10
15 Retransfer Delay Time Integer In seconds
16 Horn Volume Integer Range: 1-10
17 Critical Option Enabling Bitpacked See section 12.1.3.
18 Non-Critical Option Enabling Bitpacked See section 12.1.3.
Group 4: Event
Mask Settings
1 to 63 Event Mask settings for faults Event Mask See section 12.1.4.
64 to 143 Event Mask settings for alarms Event Mask See section 12.1.4.
Table 8 Group settings and values (continued)
Group Item Description Value Type Value Notes
