Vertiv™ NetSure™ Control Unit (NCU) User Manual
NMSV2 Configuration Description (Network Management System)
Configures SNMP Version 1 and 2 parameters.
You can configure the following parameters.
• NMS IP: The permitted IP to access the NMSV2 agent. Check the IPV6 box when entering an IPV6 address.
• Public Community: The public community string.
• Private Community: The private community string.
• Trap Enabled: Trap function enabled or disabled.
NOTE!
Only listed IP Addresses will have SNMP access.
NOTE!
To reset the form (i.e. to start over) and erase all information entered, click on the “Reset” button.
Figure 5.57 SNMP - NMSV2 Configuration (cont’d on next page)
