Vingtor Stentofon TKIS-2 - ECPIR-3 P Indoor Intercom; TKIE-2 Turbine Extended Kit

12
A100K11194
Turbine Station Conguration Guide
1.2.2 ECPIR-3P Indoor Intercom
The ECPIR-3P is an Indoor Intercom with 3 programmable keys
Speaker
PTT Key
Volume Control
Dimmer
+
Fault
LED
Call
LED
Power
LED
Figure 7 ECPIR-3P Intercom Keys & Functions
1.2.3 TKIE-2 Turbine Extended Kit
The TKIE-2 is the extended version of the Turbine Kit range.
Figure 8 TKIE-2 Connectors & Functions
