Manual VIPA CPU 21x Chapter 8 Deployment CPU 21xCAN
HB103E - Rev. 05/45 8-23
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0x1000 0 Device
Type
Unsigned32 ro N 0x00050191 Statement of device type
The 32Bit value is divided into two 16Bit fields:
MSB LSB
Additional information Device profile number
0000 0000 0000 wxyz (bit) 405dec=0x0195
The "additional information" contains data related to the signal types of the
I/O device:
z=1 digital inputs
y=1 digital outputs
x=1 analog inputs
w=1 analog outputs
Index Sub-
Index
Name Type Attr. Map. Default value Meaning
0x1001 0 Error
Register
Unsigned8 ro Y 0x00 Error register
Bit 7 Bit 0
ManSpec reserved reserved Comm. reserved reserved reserved Generic
ManSpec.: Manufacturer specific error, specified in object 0x1003.
Comm.: Communication error (overrun CAN)
Generic: A not more precisely specified error occurred (flag is set at
every error message)
Index Sub-
Index
Name Type Attr. Map. Default value Meaning
0x1005 0 COB-Id sync
message
Unsigned32 ro N 0x80000080 Identifier of the SYNC
message
The lower 11Bit of the 32Bit value contain the identifier (0x80=128dez),
while the MSBit indicates whether the device receives the SYNC telegram
(1) or not (0).
Attention: In contrast to the PDO identifiers, the MSB being set indicates
that this identifier is relevant for the node.
Device Type
Error register
SYNC identifier
