virtual access GW1000M Series User Manual

17: QoS: type of service
_______________________________________________________________________________________________________
_____________________________________________________________________________________________________
© Virtual Access 2017
GW1000 Series User Manual
Issue: 1.9 Page 134 of 350
17.4.3 Classes
Each bucket has its own configuration.
config class 'Normal'
option packetsize '1500'
option avgrate '30'
option priority '5'
config class 'Express'
option packetsize '1000'
option maxsize '800'
option avgrate '50'
option priority '10'
option limitrate '10'
UCI/Package Option
Description
UCI: qos.Normal=class
Opt: Normal
Specifies class name.
UCI: qos.Normal.packetsize=1500
Opt: packetsize
Specifies packet size for the class in bytes.
UCI: qos.Normal.avgrate=30
Opt: avgrate
Average rate for this class, value in % of bandwidth in %.
UCI: qos.Normal.priority=5
Opt: priority
Specifies priority for the class in %.
UCI: qos.Express=class
Opt: Express
Specifies class name.
UCI: qos.Express.packetsize=1000
Opt: packetsize
Specifies packet size for the class in bytes.
UCI: qos.Express.maxsize=800
Opt: maxsize
Specify max packet size in bytes.
UCI: qos.Express.avgrate=50
Opt: avgrate
Average rate for this class, value in % of bandwidth in %.
UCI: qos.Express.priority=10
Opt: priority
Specifies priority for the class in %.
UCI: qos.Express.limitrate=10
Opt: limitrate
Defines to how many % of the available bandwidth this class is
capped to.
17.4.4 Classify
Classifiers match the traffic for desired class.
config classify
option target 'Express'
option proto 'udp'
