17: QoS: type of service
_______________________________________________________________________________________________________
_____________________________________________________________________________________________________
© Virtual Access 2017
GW1000 Series User Manual
Issue: 1.9 Page 132 of 350
Figure 74: Parameters for classification rules
Web Field/UCI/Package Option
Description
Web: Target
UCI:
Opt:
Creates and configures selected target bucket.
Normal
Priority
Low
Express
Web: Source host
UCI:
Opt:
Source host.
Web: Destination host
UCI:
Opt:
Destination host.
Web: Service
UCI:
Opt:
Selectable service.
Web: Protocol
UCI:
Opt:
Protocol to classify.
Web: Ports
UCI:
Opt:
Upload speed kbits/sec.
Web: Number of bytes
UCI:
Opt:
Number of bytes for bucket.
Table 43: Information table for classification rules
17.4 Configuring QoS using UCI
You can also configure QoS using UCI. The configuration file is stored on:
/etc/config/qos
17.4.1 Interface
Defines the interface on which configured QoS settings will take place.
Each interface can have its own buffer. The interface section declares global
characteristics of the connection on which the specified interface is communicating. The
following options are defined within this section:
