17 QoS: type of service
Virtual Access routers are capable of implementing quality of service configurations on a
per interface basis, which allows traffic prioritisation based on type of service criteria
parameters.
17.1 QoS configuration overview
A minimal QoS configuration usually consists of:
 One interface section
 Some rules allocating packets to at least two buckets
 Configuration of the buckets
17.2 Configuration packages used
Package
Sections
qos
interface
classgroup
class
classify
17.3 Configuring QoS using the web interface
Browse to the router’s IP address and login.
Select Network tab -> QoS. The QoS page appears. From this page you can configure
interfaces that QoS is applied to as well as classification rules.
Figure 72: The quality of service page
To configure an interface, enter a relevant interface name and click Add. The Quality of
Service page for that interface appears.
