28: Configuring SNMP
_______________________________________________________________________________________________________
_____________________________________________________________________________________________________
© Virtual Access 2017
GW1000 Series User Manual
Issue: 1.9 Page 271 of 350
snmpd.system.sysContact=Mr White
snmpd.system.sysName=Backup Access 4
snmpd.agent=agent
snmpd.agent.agentaddress=UDP:161
snmpd.agent.authtrapenabled=yes
snmpd.agent.link_updown_notify=yes
28.3.2 System settings using package options
root@VA_router:~# uci export snmpd
package snmpd
config 'system'
option sysLocation 'Office 123'
option sysContact 'Mr White'
option sysName 'Backup Access 4'
config 'agent'
option agentaddress 'UDP:161'
option authtrapenabled '1'
option link_updown_notify '1'
Another sample agent configuration shown below causes the agent to listen on UDP port
161, TCP port 161 and UDP port 9161 on only the interface associated with the localhost
address.
config 'agent'
option agentaddress 'UDP:161,tcp:161,9161@localhost'
28.3.3 com2sec settings
The following sample specifies that a request from any source using “public” as the
community string will be dealt with using the security name “ro”. However, any request
from the localhost itself using “private” as the community string will be dealt with using
the security name “rw”.
Note: the security names of “ro” and “rw” here are simply names – the fact of a security
name having read only or read-write permissions is handled in the access section and
dealt with at a group granularity.
