Chapter 3, Vitals Hardware and Software: TC-100 Tablet Controller with Vitals Mobile-TC
E.H. Wachs Part No. 79-MAN-04, Rev. I 13
You can transfer valve and activity data between the TC-
100 and your PC running Vitals Desktop using a USB flash
drive. You can also set up the TC-100 on your network; see
your IT person/department for assistance. The TC-100 oper-
ates as a fully functional Windows 10 Pro tablet PC.
Specifications
Table 3-2: TC-100 Hardware Specifications
Operating System Microsoft Windows 10 Pro
Processor Quad-core Intel Pentium N4200
Memory 8 GB RAM
Storage Memory 128 GB. Expansion with Micro SD/SDXC slot.
Display 800 x 1280, 7” backlit LCD
Battery Life Up to 12 hours (may be reduced running GPS)
Battery Charging 4-6 hours to full charge
Ports
Data: USB 3.0 host (full A), 3.5 mm audio jack.
Power: 10-15.5 V, nominal 12 VDC.
Cameras 8 MP rear and 2 MP front
Wireless
connectivity
Bluetooth 5.0 long range wireless. Wi-Fi
801.11a/b/g/n/ac 2.4 GHz and 5 GHz..
GPS
u-blox NEO-M8N GNSS with 72 tracking chan-
nels.
Size and weight
5.4” w x 8.48” l x 1.36” d (137 mm x 215 mm x
35 mm). 1.73 lb (770 g) with battery.
Temperature
Operating: -4°F to +122°F (-20°C to +50°C)
Storage: -22°F to +158°F (-30°C to +70°C)
Charging: 32°F to +122°F (0°C to +50°C)
Environmental IP68 waterproof and dustproof
Drop
Shockproof: multiple drops from 4’ (1.2 m) onto
concrete
