Vitals Reference Manual
14 Part No. 79-MAN-04, Rev. I E.H. Wachs
California Energy Commission Compliance
The “BC” symbol on the
cover of this manual signifies
CEC compliance.
The battery charger supplied with the TC-100 has passed
testing required by California Code of Regulations Title 20,
using Test Method 10 CFR Section 430.23(aa) (Appendix Y
to Subpart B), June 2016. Information on the charger’s cer-
tification is available at:
https://cacertappliances.energy.ca.gov/Pages/Appliance-
Search.aspx
(No hyphen.) Search for company “Juniper Systems”,
model “TC-100”.
HC-100 HANDHELD CONTROLLER WITH
V
ITALS MOBILE-HC
The Bluetooth module is
rated for operation from -4°F
to +122°F (-20°C to +50°C).
The HC-100 is a ruggedized handheld computer running the
Windows Embedded Handheld operating system. It is
waterproof and can be used in temperatures from -22°F to
+140°F (-30°C to +60°C). The HC-100 has integrated GPS
and Bluetooth connectivity. See specifications below.
You can use an external GPS unit for higher-resolution
mapping. Input requires NMEA-0183 data format, using
either Bluetooth or an RS-232 cable.
Connection Options
Connection between the HC-100 and E.H. Wachs valve
operating equipment is made using either the included 79-
302-10 Machine Control Cable or the embedded wireless
Bluetooth communication in the HC-100 (requires optional
Bluetooth module installed, and may require board upgrade
on older TM machines).
The HC-100 connects to the PC running Vitals Desktop
using a USB connection. You can connect the HC-100
directly to the PC USB port (using Windows Mobile Device
Center), or transfer data using a USB flash drive.
NOTE
NOTE
