Chapter 3, Vitals Hardware and Software: HC-100 Handheld Controller with Vitals Mobile-HC
E.H. Wachs Part No. 79-MAN-04, Rev. I 15
An optional desktop dock
(79-110-09), shown in the
photo, is available to provide
power and USB connection
to the HC-100. The dock also
has an Ethernet jack for con-
necting to a network.
Specifications
Table 3-3: HC-100 Hardware Specifications
Operating System Microsoft Windows Embedded Handheld
Processor 1.0 GHz ARM Cortex A8 i.MX53
RAM 512 MB
Storage Memory 8 GB
Display 800 x 480, 4.3” WVGA LCD TFT
Battery Life
Up to 20 hours (may be reduced when
running GPS)
Battery Charging 2-4 hours to full charge
Ports
Data: USB host (full A), USB client (Micro
B), RS-232 9-pin. Power: 12, 24 VDC
input, 10-36 V unregulated.
Wireless connectivity
Bluetooth wireless, 2.1 +EDR, Class 1.5,
range greater than 100 ft (30 m). Wi-Fi
801.11b/g/n.
GPS High-sensitivity GPS/GLONASS/SBAS
Size and weight
3.6” w x 7.25” l x 1.5” d (91 mm x 184 mm
x 38 mm). 1.3 lb (590 g) with battery.
