Chapter 5, Using Vitals Mobile-TC (TC-100 Controller): Vitals Mobile Diagnostics
E.H. Wachs Part No. 79-MAN-04, Rev. I 73
Figure 5-39. Plug the diagnostics cable directly into
the circuit board in the valve operator control box.
5.
Perform the diagnostics as described earlier in this
section.
6.
When finished, reconnect the internal cable and
replace the control box cover.
Remove the internal cable from the circuit
board, and plug in the diagnostics cable
