Weber Packaging Solutions, Inc. 2-1
2
General Information
This chapter describes general functional and logistical information
regarding the machine and its use. This includes air and power source
specifications, pneumatic safety, recommendations for machine placement,
and illustrations of machine layouts and components.
Specifications
28.92 x 27.49 x 24.5” (73.45 x 69.82 x 62.23 cm)
Refer to the nameplate on the applicator for specific
voltage and amperage requirements.
Compressed Air Requirements
Compressed Air Consumption
(applying a 4x6” label with a 3.00”
stroke at 40 labels per minute
Air must be clean (i.e., free of solvents, oxidizing
agents, corrosive materials, and organic matter) and
dry (i.e., free of water and lubricants).
Filter must be drained periodically (see Chapter 7,
Maintenance).
4.6 SCFM ** @ 110 psi
Level of Noise Emission in
accordance with ISO 4871
Sound pressure level LpA (referenced 20 µPa)
measured at the operator’s station: 70 dB
Uncertainty KpA: 1 dB
Temperature 41–104° F (5–40°C)
Humidity 15–85% RH non-condensing
* Model 4300 with Zebra 170PAX4 printer, u-arm, 3.0” stroke, 6”x 4” tamp pad, and air filter:
159lbs; Full supply roll of Weber label L-6306: 21lbs.
** SCFM = standard cubic feet per minute based on the following conditions: 14.7 psia, 60° F,
and 0% relative humidity
