Controller Operation
Weber Packaging Solutions, Inc. 6-5
Active Edge
Active Edge specifies the edge of the product that is to be used to start the label application
process.
LEADING – detects the front edge of the product
TRAILING – detects the rear edge of the product
CONTINUOUS – does not wait for the product, but applies the label when the label is finished
printing.
The factory default setting is LEADING
Set Language
Use the arrow buttons to select the desired language.
English
Francois (French)
Deutsch (German)
Espanol (Spanish)
Set Timers
Air Blast
The air blast setting controls the duration of the air blast that applies the label to the
product. Various factors, such as distance of tamp pad to the product or size of the label
affect the air blast time. For optimum machine cycle time, the blast time should be just
slightly longer than the time required to apply the label firmly.
The factory default value is 125. Range is 25 to 500 milliseconds adjustable in
increments of 25 milliseconds.
Tamp Extend
The Tamp Extend setting controls the time the tamp is extended before blowing the
label onto the product. The tamp retracts once the tamp extend time is satisfied.
The factory default value is 500. Range is 0 to 500 milliseconds adjustable in
increments of 250 milliseconds.
NOTE: If the tamp extend time is set too short, the full stroke of the tamp may not be
achieved. If the tamp extend time is set too long, the label may not be applied at the
correct time or to the correct product.
NOTE: For machines equipped with the Variable Stroke Sensor Option, set the tamp
extend time to a maximum of 500ms so the timer does not interfere with the sensor.
In addition, this will prevent the tamp from staying in the extended state if a product is
not detected by the sensor.
