Weber 4300 User Manual

Chapter 9
9-12 Printer-Applicator User’s Manual
AC Wiring
GREEN/YELLOW
CHASSIS
GROUND
WHITE
LIGHT BLUE
TRANSFORMER ASSEMBLY
(#54372)
2 3
1 4
GREEN/YELLOW
1 2
L
N
5 6
7 8
11
12
BROWN
BLACK
REWIND MOTOR/POWER
SUPPLY PCB ASSEMBLY
(#55025)
J2 J1
RED RED
VIOLET VIOLET
BROWN
LIGHT BLUE
A.C. WIRING DIAGRAM
L
PE
N
L
N
POWER ENTRY
MODULE ASSEMBLY
(#54373)
FUSES:
115 VAC MACHINES: 5A, 250V
230 VAC MACHINES: 2.5A, 250V
AUXILIARY POWER
OUTLET
(#54013)
Figure 9-7: AC Wiring
