Weber 4300 - Inputs Specifications; Trigger Apply; Trigger Print

Appendix
Weber Packaging Solutions, Inc. 9-7
Pin 10
Label-On-Pad (Normally
Open)
Pin 14
Label-On-Pad (Common)
Pin 12
Data Ready (Normally Open)
Pin 15
Data Ready (Common)
Pin 11
Warning (Normally Open)
Pin 24
Warning (Common)
Pin 9
Ready (Normally Open)
Pin 22
Ready (Common)
Pins 5, 6, 7, 8, 20, and 21 have no connection.
Inputs Specifications
 Optically isolated bipolar (polarity independent)
 Input voltage 12 - 30 VDC
Trigger Apply
Triggers the application of a previously printed label waiting on the tamp pad.
Trigger Print
A trigger printing of a single label given a print job is waiting in the printer.
