Maintenance
Weber Packaging Solutions, Inc. 7-5
Tamp Home Sensor Adjustment
NOTE: THE TAMP HOME SENSOR ADJUSTMENT SHOULD ONLY BE
PERFORMED BY A QUALIFIED SERVICE TECHNICIAN.
RIGHT-HAND
MOUNTING
SCREWS
Figure 7-1: Tamp Home/Extend Sensor Adjustment
When the tamp home sensor detects that the tamp has returned, the printer receives a signal to feed and
print the next label. The sensor has a small LED that indicates when the tamp is in the home position.
The sensor may need to be readjusted periodically, or whenever the tamp height is adjusted.
