Chapter 9
9-8 Printer-Applicator User’s Manual
Trigger Signal Usage
Mode
Product
Detector
Trigger
Apply
Trigger
Print
Notes
Tamp Blow
Apply Label
Apply Label
Tamp Blow PA
Print and
Apply Label
Print and
Apply Label
One sensor or signal prints and
applies a label.
Tamp Blow PA
Apply Label
Apply Label
Print Label
Separate signals to print and
apply a label.
Air Blow
Apply Label
Apply Label
Air Blow PA
Print and
Apply Label
Print and
Apply Label
One sensor or signal prints and
applies a label.
Air Blow PA
Apply Label
Apply Label
Print Label
Separate signals to print and
apply a label.
Inverted Tamp Blow
Apply Label
Apply Label
Start
Puts the Model 4300 in Run mode from Idle mode. If an error condition caused the Model 4300
to enter Idle mode, the Start signal will not return to Model 4300 to Run mode until the error
condition is corrected.
Applicator Disable
Dynamically switches the Model 4300 between Run and Idle mode. When a voltage is applied
to the input, the Model 4300 enters Idle mode. When the voltage is removed, the Model 4300
enters Run Mode.
