Diagnostics Screen
The Diagnostics Screen allows the operator to run a test cycle, view inputs and test outputs. See the
following sections for screen and function information.
To access the diagnostics menus while the applicator is running, press [RETURN] button on the
controller keypad.
View Inputs
 Use the arrow buttons to scroll to the menu.
 Use the arrow buttons to select [DISPLAY INPUTS].
NOTE: The number (1) indicates ON and the number (0) indicates OFF.
The current inputs are:
Controller
Name
Description
IN00
Tamp Home
Tamp home sensor on tamp cylinder
IN01
Product Detector
Product detector input
IN02
Print End
Print end signal from print engine
IN03
Tamp Enable
Tamp enable switch (optional)
IN04
Variable Tamp
Tamp extended sensor on tamp pad
IN05
Media Out/Printer Error
Wire-or of label out, ribbon out, error, signals from
the print engine
IN06
Low Label Supply
Input from low label sensor
IN07
Label On Pad
Vacuum sensor on tamp pad
IN08
Start
External Input Signal
IN09
Reset Applicator Disable
External Input Signal
IN10
Not Used
-----
IN11
Low Ribbon
Ribbon low signal from the print engine
