Weber 4300 - Test Outputs; Cycle Time; Test Cycle; Return Button

Controller Operation
Weber Packaging Solutions, Inc. 6-9
Test Outputs
 Use the arrow buttons to scroll to the menu.
 Use the arrow buttons to selectively turn each signal ON and OFF.
The current outputs are:
Controller
Name
Description
OUT00
Error
Applicator is in idle or Error mode
OUT01
Ready
Applicator is in Run mode
OUT02
Label-on-Pad
A label is present on the tamp pad
OUT04
Print Start
Printer control signal
OUT05
Warning
Low supply condition
OUT06
Tamp Error
Tamp moved off home position unexpectedly
OUT07
Air Assist
OUT08
Air Blast
OUT09
Tamp
OUT10
Vacuum Control
Supplies vacuum to the applicator
Cycle Time
The cycle time feature automatically extends and retracts the tamp assembly and measures the
amount of time of time of each action takes in milliseconds. The times are displayed on the
controller
This feature is useful in adjusting the tamp cylinder flow and cushion controls to ensure the
tamp assembly does not exceed rated speeds.
Test Cycle
The test cycle is a way to check all the machine functions as they go through a normal operating
cycle.
 Use the arrow buttons to scroll to the menu.
 Use the arrow buttons to select [RUN] for a test cycle.
Return Button
The [RETURN] button on the controller keypad will clear errors once the condition causing them is
corrected. The applicator will then be placed into run mode.
