WEG CFW700 - Access to the Control and Powerterminal Strips; Access to the Control Terminal Strips; Access to the Power Terminal Strips

CFW700 | 203
Appendix A / Anexo A
Appendix A
Anexo A
Frame sizes A, B and C / Tamaños A, B y C / Mecânicas A, B e C
Access to the control and power
terminal strips
Acceso a los bornes de control y
potencia
Acesso aos bornes de controle e
potência
1 2
3
1 2
3
Frame sizes D and E / Tamaños D y E / Mecânicas D e E
Access to the control terminal strips
Acceso a los bornes de control
Acesso aos bornes de controle
1 2
3
Access to the power terminal strips
Acceso a los bornes de potencia
Acesso aos bornes de potência
1 2
