WEG CFW700 - Inverter Dimensions in MM (In)

CFW700 | 235
Appendix B / Anexo B
Appendix B
Anexo B
R3.0 [0.12]
R3.0 [0.12]
M5 (4x)
A
A
B
B
4.3 [0.17 ]
9.3 [0.36]
9.0 [0.35]
10.0 [0.39]
269.2 [10.60]
172.1 [6.78]
250.0 [9.84]
245.1 [9.65]
10.0 [0.39]
100.2 [3.94]
19 6. 2 [ 7.72]
34.7 [1.36]
10.8 [0.42]
R5.8 [0.23]
8.3 [0.32]
8.3 [0.32]
227.0 [ 8.9 4]
95.8 [3.77]
156.9 [6.18]
70.2
[2.76]
94.0 [3.70]
94.9 [3.74]
115.0 [4.53]
115.0 [4.53]
145.0 [5.71]
100.0 [3.94]
72.0 [2.83]
48.0
[1.89]
M4 (6x)
Figure B.4: Inverter dimensions in mm [in] - frame size A
Figura B.4: Dimensiones del convertidor de frecuencia en mm [in] - tamaño A
Figura B.4: Dimensões do inversor em mm [in] - mecânica A
