WEG CFW700 - Linedrive Encoder or Push-Pull and Active High Digital Inputs

20 | CFW700
Installation and Connection
English
GND (24 V)
White
REF+
AI1+
AI1-
REF-
AO1
AO2
AGND (24 V) AGND (24 V)
AI2+
AI2-
rpm
amp
+V
A A
B B
Z Z
GND
Blue
Red
Green
Yellow
Pink
GreyZ
Z B B A A
+5 V-ENC
Brown
B - RS-485
>300 Ω
DO2 DO3 DO4 DO5
+24 V
+24 V COM GND (24 V)
RL1-NA RL1-C RL1-NF
DI5
DI1
DI6
DI2
DI7
DI3
DI8
DI4
>300 Ω >300 Ω >300 Ω
Linedrive encoder or push-pull
(1)
A - RS-485
GND-ENC
≥5 kΩ
Active high digital inputs
(2)
(1) Refer to Figure 3.5 on page 21 (b) for the open-collector encoder connection.
(2) Refer to Figure 3.5 on page 21 (c) for active low digital inputs connection.
(a) Linedrive encoder or push-pull and active high digital inputs
