Option Kits and Accessories
English
Table 7.1: Accessory models
WEG (part
number)
Name Description Slot
Identification
Parameters
- P0028
Control Accessories
11 511 558 USB-RS-485/RS-422 USB-RS-485/RS-422 Interface kit. - -
11008106 CAN-01 CAN interface module (CANopen / DeviceNet). 3 CD--
11045488 PROFIBUS DP-01 Profibus DP interface module. 3 C9--
Flash Memory Module
11355980 MMF-02 FLASH memory module. 5 --xx
(1)
Expansion Module
11402038 CCK-01 Output relays module. - -
Stand-alone Keypad, Blank Cover, and Frame for Remote Mounted Keypad
11401784 HMI-02 CFW700 stand-alone keypad (HMI).
(2)
HMI -
11342535 RHMIF-02 Remote keypad frame kit (IP56). - -
10950192 1 m HMI Cable 1 m serial remote keypad cable set. - -
10951226 2 m HMI Cable 2 m serial remote keypad cable set. - -
10951223 3 m HMI Cable 3 m serial remote keypad cable set. - -
10951227 5 m HMI Cable 5 m serial remote keypad cable set. - -
10951240 7.5 m HMI Cable 7.5 m serial remote keypad cable set. - -
10951239 10 m HMI Cable 10 m serial remote keypad cable set. - -
11010298 HMID-01 Blank cover for the keypad slot. HMI -
Miscellaneous
11401877 KN1A-02 Nema1 kit for frame size A inverter.
(3)
- -
11401938 KN1B-02 Nema1 kit for frame size B inverter.
(3)
- -
11401857 KN1C-02 Nema1 kit for frame size C inverter.
(3)
- -
10960842 KN1E-01
Nema1 kit for models 105 A and 142 A of frame
size E inverter.
(3)
- -
10960850 KN1E-02
Nema1 kit for models 180 and 211 A of frame size
E inverter.
(3)
- -
11401939 KIP21A-01 IP21 kit for frame size A inverter. - -
11401941 KIP21B-01 IP21 kit for frame size B inverter. - -
11401940 KIP21C-01 IP21 kit for frame size C inverter. - -
11010264 KIP21D-01 IP21 kit for frame size D inverter. - -
11010265 PCSA-01 Kit for power cables shielding - frame size A. - -
11010266 PCSB-01 Kit for power cables shielding - frame size B. - -
11010267 PCSC-01 Kit for power cables shielding - frame size C. - -
11119781 PCSD-01
Kit for power cables shielding - frame size D
(included in the standard product).
- -
10960844 PCSE-01
Kit for power cables shielding - frame size E
(included in the standard product).
- -
12705234 PCSC-03
Kit for power cables shielding - frames sizes B
and C with degree of protection IP55.
- -
10960847 CCS-01
Kit for control cables shielding (included in the
standard product).
- -
11401942 CONRA-02
CFW700 Control Rack (includes the CC700.CDE
control board and it is supplied with the product).
- -
10790788 DBW030380D3848SZ 380...480 Vac dynamic braking module. - -
10794631 DBW030250D5069SZ 500...690 Vac dynamic braking module. - -
Notes:
(1) The identification of the MMF-02 module is presented in the bit 6 of the parameter P0028. Refer to CFW700 programming
manual.
(2) Use DB-9 pin, male-to-female, straight-through cable (serial mouse extension type) for connecting the keypad to the
inverter or Null-Modem standard cable. Maximum cable length: 10 m (33 ft).
Examples:
- Mouse extension cable - 1.80 m (6 ft); Manufacturer: Clone.
- Belkin pro series DB9 serial extension cable 5 m (17 ft); Manufacturer: Belkin.
- Cables Unlimited PCM195006 cable, 6 ft DB9 m/f; Manufacturer: Cables Unlimited.
(3) Refer to Figure B.2 on page 232.
