56 | CFW700
Troubleshooting and Maintenance
English
1 2
Cable connection Plugging in of the fan
(a) Models of frame sizes A, B, C, D and model 105 A / 380 / 480 V
1 2
Cable connection
Fastening of the fan and grid
to the product
(b) Models 142 A, 180 A and 211 A / 220 / 230 V and 380 / 480 V and all the models of 500 / 600 V
Figure 6.2: (a) and (b) Installation of the heatsink fan
