WEG CFW700 - List of Models of CFW700 Series, Main Electrical Specifications-Models 600 V

214 | CFW700
Appendix B / Anexo B
Appendix B
Anexo B
Table B.3: List of models of CFW700 series, main electrical specifications – models 600 V
Tabla B.3: Relación de modelos de la línea CFW700, especificaciones eléctricas principales – modelos 600 V
Tabela B.3: Relação de modelos da linha CFW700, especificações elétricas principais – modelos 600 V
Inverter
Convertidor
Inversor
Number of Input Phases
N° de Fases de Alimentacion
N° de Fases de Alimentacao
Power Supply Rated Voltage
Tension Nominal de Alimentacion
Tensao Nominal de Alimentacao
Frame Size / Tamaño / Mecânica
Output Rated Current
Corriente de Salida Nominal
Corrente Nominal de Saida
(1)
Maximum Motor
Motor Maximo
(2)
Recommended Fuse
Fusible Recomendado
Fusivel Fecomendado
Power Wire Size
Calibre de los Cables de Potencia
Bitola dos Cabos de Potencia
(3)
Grounding Wire Size
Calibre del Cable de Puesta a Tierra
Bitola do Cabo de Aterramento
(3)
Dynamic braking
Frenado reostatico
Frenagem reostatica
(4)
Maximum Current
Corriente Maxima
Corrente Maxima
Recommended Resistor
Resistor Recomendado
Braking rms Current
Corriente Eficaz de Frenado
Corrente Eficaz de Frenagem
Power Wire Size for DC+ and
BR Terminals
Calibre de los Cables +UD y BR
Bitola dos Cabos +UD e BR
(3)
ND HD
ND HD I²t UL WEG
(InomND) (InomHD) (Imax)
[Vrms] [Arms] [Arms] [HP/kW] [HP/kW] [A²s] [A] In[A]
Model
Modelo
[mm²] [AWG]
mm²
(AWG)
[A] [Ω] [A]
mm²
(AWG)
CFW700B02P9T5
3
500...
600
B
2.9 2.7 2/1.5 1.5/1.1 1250 20 20 FNH00-20K-A 1.5 14 2.5 (14) 36.4 33 31.9 6 (8)
CFW700B04P2T5 4.2 3.8 3/2.2 2/1.5 1250 20 20 FNH00-20K-A 1.5 14 2.5 (14) 36.4 33 31.9 6 (8)
CFW700B07P0T5 7.0 6.5 5/3.7 3/2.2 1250 20 20 FNH00-20K-A 1.5 14 2.5 (14) 36.4 33 31.9 6 (8)
CFW700B10P0T5 10 9.0 7.5/5.5 5/3.7 1250 20 20 FNH00-20K-A 2.5 14 2.5 (14) 36.4 33 31.9 6 (8)
CFW700B12P0T5 12 10 10/ 7. 5 7.5/5.5 1250 25 25 FNH00-35K-A 2.5 12 2.5 (12) 36.4 33 31.9 6 (8)
CF W700B17P0T5 17 17 15/11 10/ 7.5 1250 40 40 FNH00-40K-A 4 10 4 (10) 36.4 33 31.9 6 (8)
CFW700C22P0T5
C
22 19 20/15 15/11 2100 25 25 FNH00-40K-A 6 10 6 (10) 45.5 26.4 45.5 10 (6)
CFW700C27P0T5 27 22 25/18.5 20/15 2100 35 35 FNH00-50K-A 10 8 10 (8) 45.5 26.4 45.5 10 (6)
CFW700C32P0T5 32 27 30/22 25/18.5 2100 35 35 FNH00-63K-A 10 8 10 (8) 45.5 26.4 45.5 10 (6)
CFW700C44P0T5 44 36 40/30 30/22 2100 60 60 FNH00-80K-A 10 6 10 (6) 45.5 26.4 45.5 10 (6)
CFW700D22P0T5
D
22 19 20/15 15/11 7200 50 50 FNH00-40K-A 6 10 6 (10) 45.5 26.4 45.5 10 (6)
CFW700D27P0T5 27 22 25/18.5 20/15 7200 50 50 FNH00-50K-A 10 8 10 (8) 45.5 26.4 45.5 10 (6)
CFW700D32P0T5 32 27 30/22 25/18.5 7200 60 63 FNH00-63K-A 10 8 10 (8) 45.5 26.4 45.5 10 (6)
CFW700D44P0T5 44 36 40/30 30/22 7200 80 80 FNH00-80K-A 10 6 10 (6) 45.5 26.4 45.5 10 (6)
CFW700E53P0T5
E
53 44 50/37 40/30 39200 100 100 FNH00-80K-A 25 / 10
(5)
4 / 6
(5)
25 (4) 181.8 6.6 152.0 95 (3/0)
CFW700E63P0T5 63 53 60/45 50/37 39200 100 100 FNH00-100K-A 35 / 25
(5)
2 / 5
(5)
25 (4) 181.8 6.6 152.0 95 (3/0)
CFW700E80P0T5 80 66 75/55 60/45 39200 125 125 FNH00-125K-A 35 / 25
(5)
2 / 3
(5)
25 (4) 181.8 6.6 152.0 95 (3/0)
CFW700E0107T5 107 90 100/75 75/55 39200 160 160 FNH00-160K-A 50 1 35 (2) 181.8 6.6 152.0 95 (3/0)
CFW700E0125T5 125 107 125/90 100/75 218000 200 200 FNH00-200K-A 50 1/0 / 1
(5)
35 (2) 272.7 4.4 152.0 2 x 50 (2 x 1/0)
CFW700E0150T5 150 122 150/110 125/90 218000 250 250 FNH00-250K-A 70 / 50
(5)
2/0 / 1/0
(5)
50 (1) 272.7 4.4 152.0 2 x 50 (2 x 1/0)
