WEG CFW700 - Page 246

CFW700 | 241
Appendix B / Anexo B
Appendix B
Anexo B
R4.6 [0.18]
M8 (4x)
14 [0.55]
229 [9.02]
229.7 [9.04]
286.5 [11.28]
754 [29.69]
564.8 [22.24]
707 [27.8 3]
24 [0.94]
725 [28.54]
338.6 [13.33]
176 [6.93]
R10 [0.39]
301.3 [11.86]
32 [1.26]
250 [9.84] 250 [9.84]
129
[5.08]
172.3
[6.78]
∅28.5 [1.12] (4X)
∅22.5 [0.89] (4X)
∅50 [1.97] (3X)
375 [14.76]
A
A
B
B
R4.6 [0.18]
15 [0.59]
Figure B.10: Inverter dimensions in mm [in] - frame size D with degree of protection IP55
Figura B.10: Dimensiones del convertidor de frecuencia en mm [in] - tamaño D con grado de protección IP55
Figura B.10: Dimensões do inversor em mm [in] - mecânica D com grau de proteção IP55
