WEG SSW-06 User Manual

CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
120
Range
[Factory Setting]
Parameter Unit Description / Notes
Denestheactiontobeadoptedwhensomeerrorsrelatingtothe
Serial or Fieldbus Communication occur.
 For more information refer to the Serial Communication Manual
and/or to the Fieldbus Communication Manual for the Soft-Starter
SSW-06.
NOTE!
When Serial Communication or Fieldbus Communication is
not used, this parameter must remain at 0 (not used).
 Allows time programming for the fault detection during the serial
Modbus-RTU communication. So you can adopt an action when, for
instance, the communication with the master of the Modbus-RTU
network is lost.
For more information, refer to the Soft-Starter SSW-06 Serial
Communication Manual.
NOTE!
This parameter must remain at 0 (not used), when the serial
communication is not being used.
P314
(1)
0 to 999
Timeout Time for [ 0=Not Used ]
Serial Communication 1s
Telegram Reception
Thisparameterallowsselectingthenumberoftherstparameter,
which content will be sent from the Soft-Starter SSW-06 to the Master
of the Fieldbus network.
 For more details, refer to the Soft-Starter SSW-06 Fieldbus Commu-
nication Manual.
P315
(1)
0 to 999
Read Parameter [ 0 ]
via Fieldbus 1 -
DenestheprotocolstandardsoftheserialModbus-RTUcommu-
nication.
 For more information, refer to Serial Communication Manual for the
Soft-Starter SSW-06.
P312
(1)(2)
1 to 9
Protocol Type and [ 1=Modbus-RTU
Transfer Rate of (9600bps, no
the Serial parity) ]
Communication -
Table 6.36 - Serial Communication Protocol Type
P313 0 to 3
Serial and Fieldbus [ 0=Inactive ]
Communication Error -
Actions
(E28, E29 and E30)
Table 6.37 - Error action of the Serial and Fieldbus Communication
P312 Action
1 Modbus-RTU (9600bps, no parity)
2 Modbus-RTU (9600bps, odd parity)
3 Modbus-RTU (9600bps, even parity)
4 Modbus-RTU (19200bps, no parity)
5 Modbus-RTU (19200bps, odd parity)
6 Modbus-RTU (19200bps, even parity)
7 Modbus-RTU (38400bps, no parity)
8 Modbus-RTU (38400bps, odd parity)
9 Modbus-RTU (38400bps, even parity)
P313 Action
0 Inactive
1 Disable
2 General Disable
3 ChangestoLocal
4 Inactive
5 Fatal Fault
