Troubleshooting Guide
Fuse Terminal Extension Stud
Troubleshooting Guide 60HDdoc102619 6-18
6
4. Connect the negative cable from the charger or jumper cables to a grounded metal surface. The
mounting bolts on the bottom of the control box are an acceptable ground.
5. Charge or jump the battery until it can supply enough power to raise the saw head.
6. After the saw head is raised, remove the negative cable from ground.
7. Remove the positive cable from the extension stud.
8. Remove the extension stud from the fuse terminal and return it to its storage location.
9. Remove the battery box lid and connect the positive cable directly to the positive battery terminal.
10. Connect the negative cable to a grounded metal surface.
After the battery is completely recharged, remove the negative charger cable from ground. Remove
the positive cable from the battery and replace the battery box lid.
