Sawmill Alignment
Complete Alignment Procedure
7
7-16 60HDdoc102619 Sawmill Alignment
7.4 Complete Alignment Procedure
Frame Setup
Before performing the following alignment procedures, setup the mill on firm, level ground.
If your sawmill is stationary, with no trailer axle, lower the feet so the weight of the sawmill is evenly
supported.
If your sawmill has a trailer axle and adjustable outriggers, adjust the outriggers as follows:
LT70S: Adjust the two end outriggers on the main frame tube down just enough to lift weight from the
trailer tire.
LT70M: Adjust the front and third outriggers on the main frame tube down just enough to lift weight
from the trailer tire.
LT70L: Adjust front outriggers on the main frame tube down just enough to lift weight from the trailer
tires.
All Portable Sawmills: Adjust the outer outriggers down just so they touch the ground but do not
bear weight.
See SECTION 3
for additional setup information.
