Wood-mizer LT70L DH - 8.4 Chains; 8.5 Lube System Specifications; 8.6 Hydraulic System

Specifications
Chains
8
8-6 60doc102619 Specifications
8.4 Chains
See Table 8-6. The load capacity of the chains is listed below.
8.5 Lube System Specifications
The blade lubricating oil specifications are listed below.
8.6 Hydraulic System
See Table 8-8. The specifications of the hydraulic system are shown below.
See Table 8-9. See the table below for specifications of the hydraulic system on the LT70L Super
sawmills.
Load Capacity According to ISO No 08A-1
Power Feed Chain 22700N
Up/Down Chain 45400N
TABLE 8-6
Oil Type Manufacturer Freezing
Temperature
Ignition
Temperature
Autoignition
Temperature
ACP-1E
1
1
Waste oil must be disposed of in compliance with applicable national and local regulations.
Orlen
-20 C (-4 F
o
)
Above 140 C
(284 F)
250 C (482 F)
TABLE 8-7
Hydraulic Pump #M-300-0230 Monarch
Pressure Rating 17,25MPa (2500 PSI)
Max. Pressure 19MPa (2750 PSI)
TABLE 8-8
Hydraulic Pump Bucher
Pressure Rating 17MPa (2465 PSI)
Maximum Pressure 21MPa (3045 PSI)
TABLE 8-9






