4-17 60HDdoc102619 Sawmill Operation
before storing or sharpening.
If you are sawing in temperatures below -20
o
C (-4
o
F), remove the oil tank from the sawmill when
done sawing and store it in a warm place. Blow any remaining oil from the lube hose.
4.12 Preparing The Sawmill For Towing
The Wood-Mizer trailer package makes transporting your sawmill easy and convenient. To get your
sawmill ready for towing, follow these instructions.
1. Move the saw carriage to the front end of the sawmill. Raise the rear outriggers.
See Figure 4-2. Secure outrigger with both Locking Pin and Travel Lock Pin.
CAUTION! Be sure the outrigger base is adjusted properly before
securing in travel position with the lock pin.
CAUTION! Do not adjust the outrigger base height while there is
weight on it. Damage to the outrigger may result.
2. Move the clamp all the way in toward the main bed frame tube.
FIG. 4-2. ADJUSTABLE OUTRIGGER.
Locking Pin
Outrigger Leg
Travel Lock Pin
80_008
Adjustment
Bolt
Adjustment
Bolt
Outrigger
Leg
Travel Lock
Pin
Locking Pin
