Hydraulic Information
LT 40/70L DH Hydraulic Hoses
9
9-2 60HDdoc102619 Hydraulic Information
9.2 LT 40/70L DH Hydraulic Hoses
ID Color
Code
LENGTH
"A"
Application QTY. Wood-Mizer
Part No.
H1.
- 0,65m Hose 3/8” Section Link 1 089844
H2.
Red 0,43m Hose 3/8” Section To Oil Flow Divider. 1 089845
H3.
Orange 2,8m Hose 3/8” Middle Log Clamp, IN/OUT Cylinder
(Clamp OUT)
1 089846
H4.
White 3,0m Hose 3/8” Middle Log Clamp, IN/OUT Cylinder
(Clamp IN)
1 089847
H5.
None/Pin
k
5,4m Hose 3/8” Side Support 2 089848
H6.
Brown/
Lilac
4,1m Hose 3/8” From Side Support Valve to 2nd Log Turner 2 089849
H7
Yellow 1,8m Hose 3/8” 3rd Log Loader Cylinder (Single Loading
Arm) Bottom To Oil Flow Divider
1 089850
H8
Blue 0,72m Hose 3/8” Section Valve To 1st Tee Connector (Next
To Log Turner).
1 089851
H9
Green/Ye
llow
Green
1,2m Hose 3/8” 3rd Tee Connector To 2nd Log Loader Cyl-
inder Top/Bottom
3/8" 1ST Tee Connector To 3rd Log Loader Cylinder
Top
3 089852
H10
Red 2,0m Hose 3/8” Oil Flow Divider To 2nd Tee Connector 1 089853
H11
Yellow 2,1m Hose 3/8” 2nd Tee Connector To 1st Log Loader Cyl-
inder Bottom
1 089854
H12
Blue 1,6m Hose 3/8” 1st Tee Connector To 3rd Tee Connector 1 089855
H13
Green 1,9m Hose 3/8” 3rd Tee Connector to 1st Log Loader Cyl-
inder Top
1 089856
H14
0,7m Hose 1/4” DC Hydraulic Unit 1 089857
H15
0,25m Hose 1/4” DC Hydraulic Unit 1 089858
H16
Lilac/
Black
2,55m Hose 1/4” 3rd Toe Board 2 089859
H17
Lilac/
Black
0,85m Hose 1/4” 2nd Toe Board 2 089860
H18
Brown/Sil
ver
4,7m Hose 1/4” 1st Toe Board 2 089861
H19
Yellow 3,85m Hose 1/4” Middle Log Clamp, UP/DOWN Cylinder
Bottom
1 089862
H20
Green 3,95m Hose 1/4” Middle Log Clamp, UP/DOWN Cylinder Top 1 089863
H21
Orange 4,2m Hose 1/4” 1st Log Clamp IN/OUT (Clamp OUT) 1 089864
H22
White 4,4m Hose 1/4” Log Clamp IN/OUT (Clamp IN) 1 089865
H23
Blue/Red 4,9m Hose 1/4” 1st Clamp Up/Down 2 089866
H24
White/Or
ange
2,7m Hose 1/4” 3rd Clamp In/Out 2 089867
H25
Blue/Red 0,6m Hose 1/4” 3rd Clamp Up/Down 2 089868
TABLE 9-1
