SECTION 8 SPECIFICATIONS
8.1 Log Capacity
See Table 8-1. The dimensions of logs that can be cut on the LT70 Series sawmills are listed below.
8.2 Overall Dimensions
The overall dimensions of the LT70L Series sawmills are shown below.
LT70S LT70M LT70L LT70 WIDE
Maximum Cutting Width 36,6” (73 cm) 36,6” (73 cm) 36,6” (73 cm) 2’-9 3/4” (86 cm)
Maximum Cant Width 2’-1 1/2” (65cm) 2’-1 1/2” (65cm) 2’-1 1/2” (65cm) 2’-6 3/4” (78cm)
Maximum Log Diameter 36,6” (93 cm) 36,6” (93 cm) 36,6” (93 cm) 3’-5 1/4”
(105 cm)
Maximum Log Length
1
1
If your sawmill is equipped with a bed extension, add the bed extension length to the sawmill length capacity (e.g. in
case of BX12 add 12’, i.e. 3.6 m).
15’-11” (4.8 m) 20’-2”(6.1 m) 27’-6” (8.4m)
2
2
Depending on bed frame length
Maximum Log Weight
3
3
Sawmills equipped with bed extensions can accept heavier logs if the weight is distributed so neither the sawmill or
extension is loaded beyond the 4400 lbs. (1996 Kg) limit. Loading logs heavier than 4400 lbs. (1996 Kg) on a sawmill
equipped with a bed extension requires auxiliary log handling equipment.
4400 lbs. (1996 kg) 4400 lbs. (1996 kg) 6614 lbs. (3000 kg)
4
4
Depending on bed frame length
TABLE 8-1
