1-16 60HDdoc102619 Safety
1.3 Belt Sizes
See Table 1-2. Belt sizes are shown below.
1.4 Blade Sizes
The engine/motor size of your sawmill and the type of wood you saw should determine which blade
you choose for optimum performance.
See The Blade Handbook for blade hook angle, tooth height, and tooth set specifications.
The LT70 sawmill can be equipped with a 35 mm, 38 mm or 50 mm wide blade. The blade length for
the standard LT70 sawmill is 4.67 m, and for the LT70 WIDE sawmill is 5 m.
Description Belt Size Wood-Mizer
Part #
Motor Drive Belt ( E25 ) 3B/HB
2462La
089464
Engine Drive Belt ( D42 )
3B/HB 2462La 089464
Alternator Belt ( DC mills only )
6PK775 089465
Up/Down Drive Belt (DC mills)
AVX13x600La 092813
Blade Pulley Belts
B72.5
1
1
To insure proper blade tracking, use Goodyear, Dayco Super II, or Browning
belts only.
017922
TABLE 1-2
