SECTION 7 SAWMILL ALIGNMENT
The Wood-Mizer sawmill is factory aligned. Two alignment procedures are available to realign the
sawmill if necessary. The Routine Alignment instructions should be performed as necessary to solve
sawing problems not related to blade performance. The Complete Alignment procedure should be
performed approximately every 1500 hours of operation (sooner if you regularly transport the sawmill
over rough terrain).
7.1 Routine Alignment Procedure
Blade Installation
1. Remove the blade and check the blade wheels. Remove any sawdust buildup from the surface of the
wheels.
2. Install a clean blade and apply the appropriate tension (See Section 3.4
).
3. Check the ceramic blade guide inserts and drive side deflector plate are properly adjusted
(See Section 5.2
).
4. Adjust the idle-side cant control to track the blade (See Section 3.5
).
5. Close the blade housing covers and make sure all persons are clear of the saw head.
6. Turn the key switch to #3 position.
7. Engage the blade switch.
8. Manually spin one of the blade wheels until the blade positions itself on the blade wheels.
