Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Latched Defines whether the Relay Output will be
latched when it picks up.
inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Acknowledgem
ent
Acknowledgement Signal - An
acknowledgement signal (that
acknowledges the corresponding binary
output relay) can be assigned to each
output relay. The acknowledgement-signal
is only effective if the parameter "Latched"
is set to active.
Only available if: Latched = active
1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting Inverting of the collective signal (OR-
gate/disjunction). In combination with
inverted input signals an AND-gate can be
programmed (Conjunction).
inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Assignment 1 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting 1 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Assignment 2 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting 2 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Assignment 3 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting 3 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
