Woodward HighPROTEC - Page 151

Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Assignment 4 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting 4 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Assignment 5 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting 5 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Assignment 6 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting 6 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Assignment 7 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Inverting 7 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
Operating Mode Operating Mode Working
current
principle,
Closed-circuit
principle
Working
current
principle
[Device Para
/Binary Outputs
/BO Slot X6
/BO 3]
151 MCDGV4 DOK-HB-MCDGV4-2E
