Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Assignment 2 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Inverting 2 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Assignment 3 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Inverting 3 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Assignment 4 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Inverting 4 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Assignment 5 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Inverting 5 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Assignment 6 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
