Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Inverting 6 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Assignment 7 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Inverting 7 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 4]
Operating Mode Operating Mode Working
current
principle,
Closed-circuit
principle
Working
current
principle
[Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
t-hold To clearly identify the state transition of a
binary output relay, the "new state" is being
hold, at least for the duration of the hold
time.
0.00 - 300.00s 0.00s [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
t-Off Delay Switch Off Delay 0.00 - 300.00s 0.00s [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
Latched Defines whether the Relay Output will be
latched when it picks up.
inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
Acknowledgem
ent
Acknowledgement Signal - An
acknowledgement signal (that
acknowledges the corresponding binary
output relay) can be assigned to each
output relay. The acknowledgement-signal
is only effective if the parameter "Latched"
is set to active.
Only available if: Latched = active
1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
Inverting Inverting of the collective signal (OR-
gate/disjunction). In combination with
inverted input signals an AND-gate can be
programmed (Conjunction).
inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
156 MCDGV4 DOK-HB-MCDGV4-2E
