Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Inverting 5 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
Assignment 6 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
Inverting 6 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
Assignment 7 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
Inverting 7 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X6
/BO 5]
DISARMED Ctrl Enables and disables the disarming of the
relay outputs. This is the first step of a two
step process, to inhibit the operation or the
relay outputs. Please refer to "DISARMED"
for the second step.
inactive,
active
inactive [Service
/Test (Prot
inhibit)
/DISARMED
/BO Slot X6]
Disarm Mode CAUTION! RELAYS DISARMED in order to
safely perform maintenance while
eliminating the risk of taking an entire
process off-line. (Note: The Supervision
Contact cannot be disarmed). YOU MUST
ENSURE that the relays are ARMED AGAIN
after maintenance.
permanent,
timeout
permanent [Service
/Test (Prot
inhibit)
/DISARMED
/BO Slot X6]
t-Timeout
DISARM
The relays will be armed again after
expiring of this time.
Only available if: Mode = Timeout DISARM
0.00 - 300.00s 0.03s [Service
/Test (Prot
inhibit)
/DISARMED
/BO Slot X6]
158 MCDGV4 DOK-HB-MCDGV4-2E
