Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Force Mode By means of this function the normal Output
Relay States can be overwritten (forced) in
case that the Relay is not in a disarmed
state. The relays can be set from normal
operation (relay works according to the
assigned signals) to "force energized" or
"force de-energized" state.
permanent,
timeout
permanent [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X6]
t-Timeout Force The Output State will be set by force for the
duration of this time. That means for the
duration of this time the Output Relay does
not show the state of the signals that are
assigned on it.
Only available if: Mode = Timeout DISARM
0.00 - 300.00s 0.03s [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X6]
Input States of the Binary Output Relays on OR-5 X
Name Description Assignment via
BO1.1 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
BO1.2 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
BO1.3 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
BO1.4 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
BO1.5 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
BO1.6 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
159 MCDGV4 DOK-HB-MCDGV4-2E
