Input, Output and LED Settings
Name Description Assignment via
BO1.7 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
Ack signal BO 1 Module input state: Acknowledgement signal for the
binary output relay. If latching is set to active, the
binary output relay can only be acknowledged if
those signals that initiated the setting are fallen
back and the hold time is expired.
[Device Para
/Binary Outputs
/BO Slot X6
/BO 1]
BO2.1 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
BO2.2 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
BO2.3 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
BO2.4 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
BO2.5 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
BO2.6 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
BO2.7 Module input state: Assignment [Device Para
/Binary Outputs
/BO Slot X6
/BO 2]
