Woodward HighPROTEC - Page 166

Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Force OR3 By means of this function the normal Output
Relay State can be overwritten (forced). The
relay can be set from normal operation
(relay works according to the assigned
signals) to "force energized" or "force de-
energized" state.
Normal,
De-Energized,
Energized
Normal [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X5]
Force OR4 By means of this function the normal Output
Relay State can be overwritten (forced). The
relay can be set from normal operation
(relay works according to the assigned
signals) to "force energized" or "force de-
energized" state.
Normal,
De-Energized,
Energized
Normal [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X5]
Device Parameters of the Binary Output Relays on OR- 4 X
Parameter Description Setting range Default Menu path
Operating Mode Operating Mode Working
current
principle,
Closed-circuit
principle
Working
current
principle
[Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
t-hold To clearly identify the state transition of a
binary output relay, the "new state" is being
hold, at least for the duration of the hold
time.
0.00 - 300.00s 0.00s [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
t-Off Delay Switch Off Delay 0.00 - 300.00s 0.00s [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Latched Defines whether the Relay Output will be
latched when it picks up.
inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Acknowledgem
ent
Acknowledgement Signal - An
acknowledgement signal (that
acknowledges the corresponding binary
output relay) can be assigned to each
output relay. The acknowledgement-signal
is only effective if the parameter "Latched"
is set to active.
Only available if: Latched = active
1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
166 MCDGV4 DOK-HB-MCDGV4-2E
