Woodward HighPROTEC - Page 167

Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Inverting Inverting of the collective signal (OR-
gate/disjunction). In combination with
inverted input signals an AND-gate can be
programmed (Conjunction).
inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Assignment 1 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Inverting 1 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Assignment 2 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Inverting 2 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Assignment 3 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Inverting 3 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Assignment 4 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Inverting 4 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
167 MCDGV4 DOK-HB-MCDGV4-2E
