Input, Output and LED Settings
Parameter Description Setting range Default Menu path
Assignment 5 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Inverting 5 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Assignment 6 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Inverting 6 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Assignment 7 Assignment 1..n,
Assignment List
-.- [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Inverting 7 Inverting of the state of the assigned signal. inactive,
active
inactive [Device Para
/Binary Outputs
/BO Slot X5
/BO 1]
Operating Mode Operating Mode Working
current
principle,
Closed-circuit
principle
Working
current
principle
[Device Para
/Binary Outputs
/BO Slot X5
/BO 2]
t-hold To clearly identify the state transition of a
binary output relay, the "new state" is being
hold, at least for the duration of the hold
time.
0.00 - 300.00s 0.00s [Device Para
/Binary Outputs
/BO Slot X5
/BO 2]
t-Off Delay Switch Off Delay 0.00 - 300.00s 0.00s [Device Para
/Binary Outputs
/BO Slot X5
/BO 2]
168 MCDGV4 DOK-HB-MCDGV4-2E
