Input, Output and LED Settings
List of the Analog Outputs
Name Description
-.- No assignment
VT.f Measured value: Frequency
VT.VL12 RMS Measured value: Phase-to-phase voltage (RMS)
VT.VL23 RMS Measured value: Phase-to-phase voltage (RMS)
VT.VL31 RMS Measured value: Phase-to-phase voltage (RMS)
VT.VL1 RMS Measured value: Phase-to-neutral voltage (RMS)
VT.VL2 RMS Measured value: Phase-to-neutral voltage (RMS)
VT.VL3 RMS Measured value: Phase-to-neutral voltage (RMS)
VT.VX meas RMS Measured value (measured): VX measured (RMS)
VT.VG calc RMS Measured value (calculated): VG (RMS)
VT.VL12 THD Measured value (calculated): V12 Total Harmonic Distortion
VT.VL23 THD Measured value (calculated): V23 Total Harmonic Distortion
VT.VL31 THD Measured value (calculated): V31 Total Harmonic Distortion
VT.VL1 THD Measured value (calculated): VL1 Total Harmonic Distortion
VT.VL2 THD Measured value (calculated): VL2 Total Harmonic Distortion
VT.VL3 THD Measured value (calculated): VL3 Total Harmonic Distortion
CT Ntrl.IL1 RMS Measured value: Phase current (RMS)
CT Ntrl.IL2 RMS Measured value: Phase current (RMS)
CT Ntrl.IL3 RMS Measured value: Phase current (RMS)
CT Ntrl.IG meas RMS Measured value (measured): IG (RMS)
CT Ntrl.IG calc RMS Measured value (calculated): IG (RMS)
CT Ntrl.IL1 THD Measured value (calculated): IL1 Total Harmonic Current
CT Ntrl.IL2 THD Measured value (calculated): IL2 Total Harmonic Current
CT Ntrl.IL3 THD Measured value (calculated): IL3 Total Harmonic Current
ThR.Thermal Cap Used Measured value: Thermal Capacity Used
Sync.Slip Freq Slip frequency
Sync.Volt Diff Voltage difference between bus and line.
Sync.Angle Diff Angle difference between bus and line voltages.
Sync.f Bus Bus frequency
Sync.f Line Line frequency
Sync.V Bus Bus Voltage
Sync.V Line Line Voltage
Sync.Angle Bus Bus Angle (Reference)
Sync.Angle Line Line Angle
URTD.Windg1 Winding 1
URTD.Windg2 Winding 2
URTD.Windg3 Winding 3
URTD.Windg4 Winding 4
