Input, Output and LED Settings
Name Description
URTD.Windg5 Winding 5
URTD.Windg6 Winding 6
URTD.MotBear1 Motor Bearing 1
URTD.MotBear2 Motor Bearing 2
URTD.LoadBear1 Load Bearing 1
URTD.LoadBear2 Load Bearing 2
URTD.Aux1 Auxiliary1
URTD.Aux2 Auxiliary2
URTD.RTD Max Maximum temperature of all channels.
RTD.HottestWindingTem
p
Hottest motor winding temperature in degrees C.
RTD.Hottest
MotBearTemp
Hottest motor bearing temperature in degrees C.
PQSCr.S RMS Measured Value (Calculated): Apparent power (RMS)
PQSCr.P RMS Measured value (calculated): Active power (P- = Fed Active Power, P+ = Consumpted
Active Power) (RMS)
PQSCr.Q Measured value (calculated): Reactive power (Q- = Fed Reactive Power, Q+ =
Consumpted Reactive Power) (fundamental)
PQSCr.cos phi (±) Measured value (calculated): Power factor: Sign Convention: (+)PF:I lags V (-)PF:I
leads V
PQSCr.cos phi RMS(±) Measured value (calculated): Power factor: Sign Convention: (+)PF:I lags V (-)PF:I
leads V
PQSCr.Ws Net Absolute Apparent Power Hours
PQSCr.Wp Net Absolute Active Power Hours
PQSCr.Wp+ Positive Active Power is consumed active energy
PQSCr.Wp- Negative Active Power (Fed Energy)
PQSCr.Wq Net Absolute Reactive Power Hours
PQSCr.Wq+ Positive Reactive Power is consumed Reactive Energy
PQSCr.Wq- Negative Reactive Power (Fed Energy)
