Input, Output and LED Settings
The »System OK« LED
This LED flashes green while the device is booting. After completed booting, the LED for
System OK
lights up in
green thus signalizing that the
protection
(function) is »
activated«
. Please refer to chapter ”Self-Supervision” and to
the external document ”
Troubleshooting Guide"
to find out further information on blink codes of the
System OK
LED
LED System OK
cannot be parameterized.
219 MCDGV4 DOK-HB-MCDGV4-2E
